PRODUCTS FOR EVERY FARM
ROTARY SWEEP
THE ALLIED BY FARM KING ROTARY SWEEP CUTS CLEANING JOBS IN HALF WITH A RUGGED AND DURABLE DESIGN.
The rotary sweep is available in 5 to 7 foot sweeping widths, making sure no surface goes untouched. Rear mounted for tractors and front mounted for skid steers allows the Allied rotary sweep to easily be maneuvered around obstacles.
| 3-POINT MOUNT | ||||||
|---|---|---|---|---|---|---|
| Model | 6032P | 6032W | 7232P | 7232W | 8432P | 8432W |
| Width | 69" | 69" | 81" | 81" | 93" | 93" |
| Sweeping Width | 60" | 60" | 72" | 72" | 84" | 84" |
| Weight | 640 lb | 640 lb | 740 lb | 840 lb | 740 lb | 840 lb |
| SKID STEER MODELS | ||||||
|---|---|---|---|---|---|---|
| Model | 6032P | 6032W | 7232P | 7232W | 8432P | 8432W |
| Width | 69" | 69" | 81" | 81" | 93" | 93" |
| Sweeping Width | 60" | 60" | 72" | 72" | 84" | 84" |
| Weight | 640 lb | 640 lb | 740 lb | 740 lb | 840 lb | 840 lb |
Features
- Top quality rotary brooms for use by contractors, municipalities, institutions and farmers
- Remove dirt, sand, gravel and trash from construction entrances, parking lots, bridges, driveways and sidewalks
- Remove thatch and prepare turf for the growing season
- Clean snow or leaves from streets, driveways and building entrances
- Excellent for general clean up before sealing or repairing pavement
3-POINT PTO
- PTO driven 3-pt. tractor mount in 5-ft., 6-ft., & 7-ft. widths with 32" diameter brushes
- Double gearbox drive for smooth power transmission and easy reversal of brush rotation
- Broom angles 30° right or left
- Parking stands standard
SKID STEER MODELS
- Hydraulically driven skid steer models in 5-ft., 6-ft., & 7-ft. widths with 32" diameter brushes
- Variable flow control valve for optimum broom speed
- Step-through mount design for easy in/out of skid steer cab
- Broom angles 30° right or left
Manuals
| 3-POINT MOUNT | Date Posted |
|---|---|
| Operator and Parts Manual - 2010 | July 2010 |
| SKID STEER MODELS | Date Posted |
|---|---|
| Operator and Parts Manual - 2010 | July 2010 |
